Low-temperature phase (LTP) MnBi has the hexagonal NiAs structure and retains its ferromagnetic phase up to 613 K [1]. Above 613 K, some Mn atoms from the octahedral sites diffuse into the trigonal-bipyramidal sites, resulting in the antiferromagnetic coupling between Mn at the octahedral and Mn at the trigonal-bipyramidal interstitial sites. Therefore, the magnetic moment sharply drops before reaching the Curie temperature (&lt;i&gt;T&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;) of 720 K. Spin reorientation of LTP MnBi occurs at about 90 K from &lt;i&gt;ab&lt;/i&gt;-plane (0 - 90 K) to &lt;i&gt;c&lt;/i&gt;-axis (T &amp;gt; 90 K) [2]. The spin orientation and magnetocrystalline anisotropy of LTP MnBi can be tuned by partially replacing Bi of MnBi with the third element. Sakuma et al. have performed first-principles calculations on Sn-doped MnBi (MnBi&lt;sub&gt;1-x&lt;/sub&gt;Sn&lt;sub&gt;x&lt;/sub&gt;) and found that the &lt;i&gt;K&lt;sub&gt;u&lt;/sub&gt;&lt;/i&gt; increases to about 3 MJ/m&lt;sup&gt;3&lt;/sup&gt; at x = 0.1 from - 0.5 MJ/m&lt;sup&gt;3&lt;/sup&gt; at x = 0 and then remains unchanged up to x = 0.3, and &lt;i&gt;T&lt;/i&gt;&lt;sub&gt;C &lt;/sub&gt;is 580 K for x = 0 [3]. These calculated &lt;i&gt;K&lt;/i&gt;&lt;sub&gt;u &lt;/sub&gt;and &lt;i&gt;T&lt;/i&gt;&lt;sub&gt;C&lt;/sub&gt; for x = 0 are much larger and lower than experimental -0.2 MJ/m&lt;sup&gt;3&lt;/sup&gt; and 720 K, respectively. Sakuma et al. did not relax MnBi&lt;sub&gt;1-x&lt;/sub&gt;Sn&lt;sub&gt;x&lt;/sub&gt; (x &amp;gt; 0) to estimate lattice constants, but used the lattice constants (x = 0) for MnBi&lt;sub&gt;1-x&lt;/sub&gt;Sn&lt;sub&gt;x&lt;/sub&gt; (x &amp;gt; 0). Therefore, the calculated &lt;i&gt;K&lt;/i&gt;&lt;sub&gt;u&lt;/sub&gt; and magnetic moment for x &amp;gt; 0 would be inaccurate.&lt;br/&gt;In this study, hexagonal crystal structures of LTP MnBi and Sn-doped MnBi in Fig. 1 were used. The LTP MnBi unit cell has two Mn atoms at the octahedral 2&lt;i&gt;a&lt;/i&gt; sites of (0, 0, 0) and (0, 0, 1/2) and two Bi atoms at the 2&lt;i&gt;c&lt;/i&gt; sites of (1/3, 2/3, 1/4) and (2/3, 1/3, 3/4) [4]. We have relaxed MnBi&lt;sub&gt;1-x&lt;/sub&gt;Sn&lt;sub&gt;x&lt;/sub&gt; (x = 0, 0.5) unit cell to obtain lattice constants &lt;i&gt;a&lt;/i&gt; and &lt;i&gt;c&lt;/i&gt;. Doped Sn decreases the &lt;i&gt;a&lt;/i&gt; and &lt;i&gt;c&lt;/i&gt; from 4.287 and 6.118 Å for x = 0 to 3.954 and 5.456 Å for x =0.5, respectively. Accordingly, the volume and c/a ratio also decrease from 97.37 Å&lt;sup&gt;3&lt;/sup&gt; and 1.43 (x = 0) to 73.87 Å&lt;sup&gt;3 &lt;/sup&gt;and 1.38 (x = 0.5), respectively. These relaxed lattice constants (x = 0) are in good agreement with the experimental lattice constants [5, 6].&lt;br/&gt;The WIEN2k package based on density functional theory (DFT) and using the full-potential linearized augmented plane wave (FPLAPW) method was used to conduct the first-principles calculations [7]. In order to calculate spin-polarization and spin-orbit coupling, we used the DFT within the local-spin-density approximation (LSDA) and 19 × 19 × 27 k-point mesh generating 1400 k-points in the irreducible part of the Brillouin zone.&lt;br/&gt;Figure 2 shows density of states for MnBi&lt;sub&gt;1-x&lt;/sub&gt;Sn&lt;sub&gt;x&lt;/sub&gt; (x = 0, 0.5). The net magnetic moments per formula unit is 3.613 &lt;i&gt;μ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt;/&lt;i&gt;f.u.&lt;/i&gt; for x = 0 and 2.517 &lt;i&gt;μ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt;/&lt;i&gt;f.u.&lt;/i&gt; for x = 0.5. The net magnetic moment decreases as the Sn concentration increases. The corresponding saturation magnetization in the unit of Tesla (T) monotonically decreases to 0.794 from 0.865 T as the Sn concentration increases to x = 0.5. Calculated magnetic moment of 3.613 &lt;i&gt;μ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt;/&lt;i&gt;f.u.&lt;/i&gt;, &lt;i&gt;K&lt;/i&gt;&lt;sub&gt;u&lt;/sub&gt; of -0.2 MJ/m&lt;sup&gt;3&lt;/sup&gt; and &lt;i&gt;T&lt;/i&gt;&lt;sub&gt;C &lt;/sub&gt;of 711 &lt;i&gt;K&lt;sub&gt;u&lt;/sub&gt;&lt;/i&gt; for x = 0 are in good agreement with the previously reported results [8].&lt;br/&gt;We will present&lt;i&gt; K&lt;/i&gt;&lt;sub&gt;u&lt;/sub&gt; and magnetic moment as a function of Sn concentration and discuss the discrepancy between Sakuma’s results and this work.

**References:**

[1] A. F. Andersen, &lt;i&gt;Acta Chemica Scandinavica&lt;/i&gt; 21, 1543 (1967).&lt;br/&gt;[2] Michael A. McGuire, Huibo Cao, Bryan C. Chakoumakos, and Brian C. Sales, &lt;i&gt;Phys. Rev.&lt;/i&gt; B 90, 174425 (2014).&lt;br/&gt;[3] Akimasa Sakuma, Yuki Manabe, and Yohei Kota, &lt;i&gt;Journal of the Physical Society of Japan &lt;/i&gt;82, 073704 (2013).&lt;br/&gt;[4] http://materials.springer.com/isp/crystallographic/docs/sd_1823960, 2020 (accessed 11 November 2020).&lt;br/&gt;[5] B. W. Roberts, &lt;i&gt;Phys. Rev&lt;/i&gt;. 104, 607 (1956)&lt;br/&gt;[6] Wenyong Zhang et al., &lt;i&gt;APL Mater.&lt;/i&gt; 7, 121111 (2019)&lt;br/&gt;[7] P. Blaha, et al., WIEN2K: An Augmented Plane Wave + Local Orbitals Program for Calculating Crystal Properties (Karlheinz Schwarz, Techn. Universitat, Wien, Austria, 2001)&lt;br/&gt;[8] J. Köhler et al., &lt;i&gt;J. Phys.: Condens. Matter &lt;/i&gt;8, 8681(1996)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/153d31d85f39c335487004e072bb1ff7.jpg)
Fig. 1. Crystal structure for (a) MnBi and (b) MnBi&lt;sub&gt;0.5&lt;/sub&gt;Sn&lt;sub&gt;0.5&lt;/sub&gt;

![](https://assets.underline.io/uploads/markdown_image/1/image/1e46ae3b4980f8fe52a17d3b94569416.jpg)
Fig. 2. Density of states for (a) MnBi and (b) MnBi&lt;sub&gt;0.5&lt;/sub&gt;Sn&lt;sub&gt;0.5&lt;/sub&gt;
