Two-dimensional magnetic (2DM) van der Waals (vdW) materials have attracted significant attention over the last few years, after the first experimental demonstration of ferromagnetism persisting down to the monolayer limit [1]. Since then, new vdW 2DM materials emerge frequently, covering a broad spectrum of diverse properties also found in other 3D counterpart systems – ferro/antiferromagnetism (FM/AFM), metallic/semiconducting behaviour and many non-trivial electronic phases. Out of this expanding pool of 2DM, one category that stands out is FMs with strong out-of-plane anisotropy, which present superior qualities desirable for magnetic random-access memory and other spintronic applications.&lt;br/&gt;Fe&lt;sub&gt;3&lt;/sub&gt;GeTe&lt;sub&gt;2&lt;/sub&gt; (FGT) is a prominent member of this family that features a lot of interesting properties, such as a relatively high, thickness-dependent T&lt;sub&gt;c&lt;/sub&gt; (150 K – 220 K) that can be tuned to room temperature by doping, high spin-orbit coupling originating from a strongly correlated electronic system, application in spin valves, topological phases and Kondo behaviour, amongst others [2]. FGT is a quasi-2D itinerant ferromagnetic metal, and its structure consists of Fe&lt;sub&gt;3&lt;/sub&gt;Ge layers sandwiched by single-atom layers of Te. Among the FGT layers, Te atoms are bonded together by vdW forces, allowing for exfoliation of the material in ultra-thin flakes with the scotch-tape exfoliation technique.&lt;br/&gt;Despite the considerable efforts that have already taken place in order to determine the underlying micromagnetic structure and behaviour of FGT, its highly anisotropic and non-trivial nature has not yet allowed for a consensus in the relevant scientific community. Our work therefore aims to shed light for the case of quasi-bulk FGT, by combining magnetic susceptibility measurements and Raman spectroscopy [3].&lt;br/&gt;Our magnetometry study picks up the main point of controversy around FGT, which is a kink found below the Curie temperature, roughly at 150 K. This possible magnetic transition has been shown to represent a FM to AFM interlayer coupling between the vdW bonded layers [5], however it has been argued that this can be due to different reasons, such as domain wall pinning effects. A temperature dependent Raman study can provide further insight by indirectly detecting a phase change – electronic reconfiguration leads to a qualitative change in the Raman signal, and that is what our results suggest (Fig. 1). The separation between the Raman peaks is a possible sign of this magnetic transition, a signature that often accompanies other 2D material related properties and transitions however rarely related to magnetic properties.&lt;br/&gt;Additionally, it has been shown that variations in the sample history, i.e. temperature and applied magnetic field (as well as number of atomic layers), result in different magnetic phases, such as labyrinth and stripe domains, bubble-like lattice and possibly skyrmion phases [4]. Our systematic magnetometry study provides insight regarding the formation of these different magnetic states, following three different magnetization protocols, namely: zero-field cooling (ZFC), field cooling (FC) and field warming (FW) methods (Fig. 2). The magnetometry results are correlated to Raman responses, examined up to 2&lt;sup&gt;nd&lt;/sup&gt; order. Particular interest arises from a prominent feature (a 2&lt;sup&gt;nd&lt;/sup&gt; kink below 150 K) that has not been observed before – suggesting the existence of possibly another magnetic phase. Our results advance the understanding of the underlying mechanisms of Fe&lt;sub&gt;3&lt;/sub&gt;GeTe&lt;sub&gt;2&lt;/sub&gt;, an important 2DM that is often incorporated in spintronic vdW heterostructures and devices.

**References:**

C. Gong, L. Li and X. Zhang, Nature, Vol 546, p. 265-269 (2017)&lt;br/&gt;Y. Deng, Y. Yu and Y. Zhang, Nature, Vol 563, p. 94-99 (2018)&lt;br/&gt;L. Du, J. Tang and Z. Sun, Adv. Funct. Mat., Vol 29 (2019)&lt;br/&gt;H. Wang, C. Wang and J. Li, APL, Vol 116 (2020)&lt;br/&gt;J. Yi, H. Zhuang and Z. Gai, 2D Materials, Vol 4 (2020)

**Images:**

![](https://s3.eu-west-1.amazonaws.com/underline.prod/uploads/markdown_image/1/image/c55428df00e41337ff9c7e60ce6809c6.jpg)
Fig. 1: Temperature-dependent Raman response: a) 2&lt;sup&gt;nd&lt;/sup&gt; order Raman susceptibility. b) Temperature dependent separation of the peaks @150 and @120 cm&lt;sup&gt;-1&lt;/sup&gt;

![](https://s3.eu-west-1.amazonaws.com/underline.prod/uploads/markdown_image/1/image/5131d011fc9a59caf031435ea40dcbe4.jpg)
Fig. 2: Magnetization measurements of quasi-bulk FGT: FC, FW and ZFC protocols obtained under different applied magnetic fields. a) H&lt;sub&gt;appl. &lt;/sub&gt;= 10 mT, b) H&lt;sub&gt;appl. &lt;/sub&gt;= 50 mT, c) H&lt;sub&gt;appl. &lt;/sub&gt;= 100 mT, d) a magnetometry feature (kink) position in temperature under varied applied H field (arrows in a, b, c)
