France



Recently, new energy electrical vehicles have a great development. To achieve longer driving range and higher acceleration performance at defined battery capacity and driving conditions, there is a demand of high efficiency and high torque-speed characteristics for electrical drive machines [1-2]. One of solutions is to use rectangular conductors, e.g. hair-pin winding. It can enhance the slot filling ratio to simultaneously decrease resistance and increase heat transfer ability. Furthermore, the tooth can be kept enough width and benefits for peak performance. The peak performance in new energy electrical vehicles generally require short duration (10-60 seconds) at each speed within an allowable temperature rise (Depend on the insulation level of winding and starting temperature). However, due to the strong skin effect, the current distribution in conductors become more and more uneven with speed rising. This will bring overheat risks at high speed because the temperature rising rate in short duration is closely related to the copper loss density.&lt;br/&gt;In this paper, a new peak torque-speed characteristics estimation method for these machines is proposed. Not only supplied maximal voltage and current limitation are considered, but also the skin effect of conductors and transient thermal issues are investigated. The copper loss density in the last conductor which has severest skin effect can be theoretically kept constant from some speed.&lt;br/&gt;Firstly, the supplied maximum voltage (U&lt;sub&gt;m&lt;/sub&gt;) and current (I&lt;sub&gt;m&lt;/sub&gt;) are defined according to the capability of battery and power electronic unit (PEU). The electromagnetic torque (Te), d-axis voltage (Ud), q-axis voltage (Uq) and terminal voltage (Us) are calculated under specified lead angle and current intervals. By scanning all points and based on MTPA and MTPV, the conventional peak torque-speed curve is acquired.&lt;br/&gt;Secondly, to apply the temperature rising limitation, an analytical equation on basis of the conductor size, position and frequency is used and the AC resistance of active parts of conductors is calculated [3].&lt;br/&gt;r&lt;sub&gt;N&lt;/sub&gt;/r&lt;sub&gt;dc=&lt;/sub&gt;φ(ξ)+N(N-1)ψ(ξ)&lt;br/&gt;r&lt;sub&gt;N&lt;/sub&gt; represents the AC resistance at some speed due to the skin effect and r&lt;sub&gt;dc&lt;/sub&gt; represents the DC resistance. Both are only related to the conductors in stator lamination core. The functions φ(ξ) and ψ(ξ) are related to the frequency and conductor size because ξ is expressed by the ratio of conductor height and skin depth. To keep the highest copper loss density constant with speed rising, the current limitation I&lt;sub&gt;m&lt;/sub&gt; shall be decreased with speed rising according to below question.&lt;br/&gt;I&lt;sub&gt;m&lt;/sub&gt;=I&lt;sub&gt;b&lt;/sub&gt;/√(φ(ξ)+N(N-1)ψ(ξ))&lt;br/&gt;where I&lt;sub&gt;b&lt;/sub&gt; is the current limitation at the base speed n&lt;sub&gt;b&lt;/sub&gt;. At this base speed, the copper loss density reaches the maximum allowable value. It can be defined through thermal simulation or measurement. N represents the ID of conductors in stator slot which starts counting from slot bottom.&lt;br/&gt;φ(ξ)=ξ(sh(2ξ)+sin(2ξ))/(ch(2ξ)-cos(2ξ))&lt;br/&gt;ψ(ξ)=2ξ(sh(ξ)-sin(ξ))/(ch(ξ)+cos(ξ))&lt;br/&gt;In the end, the maximum torque at each speed with similar temperature rising level in short duration will be found out and improved peak torque and power curves are finally outputted. A typical PMSM with 8 poles and 48 slots are investigated. Figure 1 and 2 show the comparison results between the conventional and proposed methods.&lt;br/&gt;&lt;br/&gt;Based on CFD simulation or measurements, the maximum copper loss density can be defined under specified S2 work condition. The special prototype with 20 thermal couples in the stator is built. The simulated torque-speed curve and measured hotspots are compared. It verifies the good effectiveness of the proposed method.

**References:**

[1] Z.Q.Zhu and D. Howe, Proceedings of the IEEE, Vol:95, 2007.&lt;br/&gt;[2] L. Sepulchre, M. Fadel, IEEE Transactions on Industry Application, p6081-6089, Vol:54, 2018.&lt;br/&gt;[3] D. Lin and P. Zhou, ICEMS, p3810-3814. Nov. 2008.&lt;br/&gt;[4] J. Brauer, IEEE Transactions on Magnetics, Vol: 18, Mar 1982

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/06c8a22958201169c3cffedcfe1bea96.jpg)
Comparison of peak torque and power performance between conventional and proposed methods

![](https://assets.underline.io/uploads/markdown_image/1/image/e3d42ed2af385d786bd3ed8faff91a1e.jpg)
Comparison of copper loss densities in the last conductor of stator slot between conventional (dash line) and proposed (solid line) methods

INTERMAG 2021

 Torque-Speed Characteristics Evaluation for Permanent Magnet Synchronous Motors with Rectangular Conductors

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Recently, new energy electrical vehicles have a great development. To achieve longer driving range and higher acceleration performance at defined battery capacity and driving conditions, there is a demand of high efficiency and high torque-speed characteristics for electrical drive machines [1-2]. One of solutions is to use rectangular conductors, e.g. hair-pin winding. It can enhance the slot filling ratio to simultaneously decrease resistance and increase heat transfer ability. Furthermore, the tooth can be kept enough width and benefits for peak performance. The peak performance in new energy electrical vehicles generally require short duration (10-60 seconds) at each speed within an allowable temperature rise (Depend on the insulation level of winding and starting temperature). However, due to the strong skin effect, the current distribution in conductors become more and more uneven with speed rising. This will bring overheat risks at high speed because the temperature rising rate in short duration is closely related to the copper loss density. In this paper, a new peak torque-speed characteristics estimation method for these machines is proposed. Not only supplied maximal voltage and current limitation are considered, but also the skin effect of conductors and transient thermal issues are investigated. The copper loss density in the last conductor which has severest skin effect can be theoretically kept constant from some speed. Firstly, the supplied maximum voltage (Um) and current (Im) are defined according to the capability of battery and power electronic unit (PEU). The electromagnetic torque (Te), d-axis voltage (Ud), q-axis voltage (Uq) and terminal voltage (Us) are calculated under specified lead angle and current intervals. By scanning all points and based on MTPA and MTPV, the conventional peak torque-speed curve is acquired. Secondly, to apply the temperature rising limitation, an analytical equation on basis of the conductor size, position and frequency is used and the AC resistance of active parts of conductors is calculated [3]. rN/rdc=φ(ξ)+N(N-1)ψ(ξ) rN represents the AC resistance at some speed due to the skin effect and rdc represents the DC resistance. Both are only related to the conductors in stator lamination core. The functions φ(ξ) and ψ(ξ) are related to the frequency and conductor size because ξ is expressed by the ratio of conductor height and skin depth. To keep the highest copper loss density constant with speed rising, the current limitation Im shall be decreased with speed rising according to below question. Im=Ib/√(φ(ξ)+N(N-1)ψ(ξ)) where Ib is the current limitation at the base speed nb. At this base speed, the copper loss density reaches the maximum allowable value. It can be defined through thermal simulation or measurement. N represents the ID of conductors in stator slot which starts counting from slot bottom. φ(ξ)=ξ(sh(2ξ)+sin(2ξ))/(ch(2ξ)-cos(2ξ)) ψ(ξ)=2ξ(sh(ξ)-sin(ξ))/(ch(ξ)+cos(ξ)) In the end, the maximum torque at each speed with similar temperature rising level in short duration will be found out and improved peak torque and power curves are finally outputted. A typical PMSM with 8 poles and 48 slots are investigated. Figure 1 and 2 show the comparison results between the conventional and proposed methods. Based on CFD simulation or measurements, the maximum copper loss density can be defined under specified S2 work condition. The special prototype with 20 thermal couples in the stator is built. The simulated torque-speed curve and measured hotspots are compared. It verifies the good effectiveness of the proposed method.

**References:**

[1] Z.Q.Zhu and D. Howe, Proceedings of the IEEE, Vol:95, 2007. [2] L. Sepulchre, M. Fadel, IEEE Transactions on Industry Application, p6081-6089, Vol:54, 2018. [3] D. Lin and P. Zhou, ICEMS, p3810-3814. Nov. 2008. [4] J. Brauer, IEEE Transactions on Magnetics, Vol: 18, Mar 1982

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/06c8a22958201169c3cffedcfe1bea96.jpg)
Comparison of peak torque and power performance between conventional and proposed methods

![](https://assets.underline.io/uploads/markdown_image/1/image/e3d42ed2af385d786bd3ed8faff91a1e.jpg)
Comparison of copper loss densities in the last conductor of stator slot between conventional (dash line) and proposed (solid line) methods

poster

I. Introduction The electric vehicle market is expanding, and the demand for components related to electrification of powertrains is increasing rapidly. There is a traction motor as a related key component, and interior permanent magnet synchronous motor (IPMSM) having excellent efficiency and power density is mainly applied [1]. In addition, NdFeB permanent magnet (NdFeB-PM) with high energy product is used for traction IPMSM. However, NdFeB-PM is expensive and there is an issue with stable supply. As a traction motor without NdFeB-PM, there have been representative studies in terms of permanent magnet assisted-synchronous reluctance motor (PMa-SynRM) using ferrite-PM, switched reluctance motor (SRM) and separately excited synchronous motor (SESM) [2-4]. However, PMa-SynRM with ferrite-PM has a lower power density than conventional IPMSM. SRM structurally has a major issue with acoustic noise and SESM has a disadvantage that requires a separate device for generating the field flux of the rotor. Recently, in order to reduce the amount of NdFeB-PM in IPMSM, there is a study on a hybrid-type PM motor (HPMM) that simultaneously applies ferrite-PM to the rotor [5-7]. However, if the HPMM does not have a stator, there is a problem that ferrite-PM become demagnetized due to the strong leakage flux of NdFeB-PM [5-6]. In addition, in order to achieve the same torque density as the target IPMSM, there are problems in that the use of ferrite-PM must be increased by reducing the inner diameter of the rotor [7]. Therefore, in this paper, we solve these problems and propose a new HPMM based on a trapezoidal ferrite-PM that has the same torque density as the traction motor of Nissan Leaf electric vehicle commercialized in 2018, the target motor. At the same time, the proposed HPMM reduces the use of NdFeB-PM by 30% and the total PM cost by 14.8% compared to the target motor. II. Structure of the Proposed HPMM Fig. 1 (a) and (b) show the ¼ rotor cross-sectional view of the proposed HPMM and the target motor. The stator of the two motors is identical, which is the stator of the 2018 Nissan Leaf traction motor. In the proposed motor, NdFeB-PM and ferrite-PM are arranged on the d-axis direction. When the two types of PM are arranged in the d-axis direction, the leakage flux of NdFeB-PM converges by itself or is aligned in the same direction as the magnetization direction of ferrite-PM, so that demagnetization of ferrite-PM does not occur. However, since the permeability of the magnet is almost similar to that of air, this structure generates a high reluctance of the d-axis, resulting in a decrease in magnet torque of IPMSM. To overcome this point, the q-axis flux path is enlarged by applying trapezoidal ferrite-PM. That is, the d-axis inductance decreases as the d-axis reluctance increases, but the q-axis inductance is maintained or increased according to the expansion of the q-axis flux path, thereby improving the reluctance torque. These characteristics are expressed in Fig. 1 (a), the performance of the proposed HPMM and the target motor are predicted by FEM using commercial software, JMAG-Designer and Solidworks under the same operating condition. III. FEA Verification Fig. 1 (c) is the flux density distribution of the rotor in the absence of a stator. The temperature of the PM was selected as -40 degC considering the low-temperature demagnetization of ferrite-PM and the automotive environment temperature range. As described in Chapter II above, it is shown that demagnetization of ferrite-PM is not generated by the leakage flux of NdFeB-PM. The lowest flux density of ferrite-PMs is 0.3 T, which is not less than knee point of 0.05 T. Fig. 1 (d) shows the average torque for each phase angle β of the proposed HPMM and target motor. The input current is 465 A, the maximum current of the target motor, and PMs temperature is 100 degC. In β = 0 deg, which means magnet torque, the magnet torque of the proposed HPMM is 198 Nm, which is 27.5 Nm lower than that of the target motor. However, with the improved reluctance torque of the proposed HPMM, the maximum torque is 336.9 Nm, which is almost the same as the target motor. Fig. 1 (e) shows the results of the mechanical stress analysis of the rotor at a maximum speed of 10,500 rpm. Since the traction motor for an electric vehicle performs variable speed operation control over a wide speed range, it is required to secure a safety factor for rotor rigidity at the maximum speed. In Fig 1 (e), based on the same analysis conditions and material properties, the maximum stresses of the proposed HPMM and the target motor are 305 MPa and 351 MPa. Based on the yield stress of the electrical steel sheet, 420 MPa, the safety factors are 1.38 and 1.2, respectively. Table I shows the specifications of the proposed HPMM and target motor. The proposed HPMM realizes the same torque density as the target motor, and at the same time reduces the usage of NdFeB-PM by 30 % and the total PM cost by 14.8 %. IV. Summary This paper proposes a new HPMM for electric vehicle traction motor. The proposed HPMM solves the problem of existing HPMM and realizes the same torque density as the target motor, Nissan leaf traction motor. At the same time, the proposed HPMM reduces the usage of NdFeB-PM by 30 % and the total PM cost by 14.8 % compared to the target motor.

**References:**

[1] K. T. Chau, et al, IEEE Trans. Ind. Electron., vol. 55, no. 6, pp. 2246–2257 (2008) [2] M. Obata, et al, in Proc. Eur. Conf. Power Electron. Appl., pp. 1–9 (2013) [3] K. Kiyota, et al, IEEE Trans. Ind. Appl., vol. 48, no. 6, pp. 2303–2309 (2012) [4] C. Stancu, et al, IEEE Trans. Ind. Appl., vol. 54, no. 1, pp. 223–232 (2018) [5] C. L. Lim, et al, IEEE Trans. Magn., vol. 53, no. 11, Art. no. 8110904 (2017) [6] C. L. Lim, et al, IEEE Trans. Ind. Appl., vol. 55, no. 5, pp. 4692-4701 (2019) [7] Z. Zhang, IEEE Energy Conversion and Exposition, DOI: 10.1109/ECCE44975.2020.9235708 (2020)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/5db93ba58daa0d53cba74fdc9b2b11fe.jpg)
Fig. 1. Rotor structure and FEA results (a) Proposed HPMM (b) Target motor (c) Magnetic flux density distribution without stator (d) Average torque by current phase angle β (e) Mechanical stress analysis results at rotational speed 10,500rpm

![](https://assets.underline.io/uploads/markdown_image/1/image/a7827f24c41627982c8a3e7c525a9dea.jpg)

 Design of Hybrid-Type PM Motor for Electric Vehicle Traction using Trapezoidal Ferrite-PM to improve Reluctance Torque

The Interior Permanent Magnet Synchronous Motor (IPMSM) is mainly used as a driving motor for Electric Vehicles (EVs) due to its advantage for high-power density and wide speed operation range. Because of the characteristics of EVs motor, it is necessary to perform high-speed driving at a small load condition. Thus, IPMSM is controlled by the field weakening control method to meet a wide operation range, which controls the phase angle through the d- and q-axis transformation. However, as the phase angle increases, the air-gap magnetic flux contains more harmonics and thus becomes less controllable, which has the drawback that there is a limit to the operation range. Moreover, in the case of large commercial EVs, high torque is required at low speed for the driving stability and the gradeability. Thus, to perform high torque at low speed, the motor should have a large permanent magnet in the motor. As the field magnetic flux increases, the back EMF also increases, so a larger phase angle is required for high-speed operation. However, the maximum speed that can be driven through the field weakening control is decreased because of the harmonics. For high-speed driving of commercial EVs, an optimal design method is needed to expand the field weakening region. The reason why the existence of a maximum speed limit is the increased harmonic component as the phase angle increases. In this paper, we divided the design part into the rotor and the stator. And then the effect on the field weakening control is analyzed when the design variables are changed. Finally, a motor design method for high-power at low-speed mode with a wide operation range is proposed by reducing harmonics and enhancing the back EMF controllability. To analyze the effects of the harmonics and the field weakening control characteristics as the design variable changed, no-load analysis is performed according to the number of slots per phase per pole. In the load analysis, the variation of line voltage is analyzed according to the current value when the maximum demagnetizing magnetomotive force is applied. Fig.1 represents that the larger the number of slots per phase per pole, the more stable voltage can be controlled. Namely, the voltage can be decreased by varying the current value and phase angle at a specific speed. It means that the limitation of the field weakening region can be possible calculated. Next, the field weakening control characteristic is analyzed according to the variation of the number of conductors per slot. Although the number of conductors per slot can reduce copper loss, it needs to prepare the countermeasure against voltage rising for field weakening control. To compare the effect according to the number of conductors in the field weakening region, the voltage values according to the number of turns are analyzed under the condition given the maximum demagnetizing magnetomotive force. The maximum operating speed considering the voltage limitation is selected. In consequence, fewer conductors in the slot are more advantageous for high-speed operation, but the rising current for voltage control and torque generation must be considered. The characteristic of field weakening control is analyzed by changing the magnet layer and shape, and the harmonic reduction analysis is implemented by the skewed method. Prior to the design of permanent magnet shape, permanent magnet with multi-layer structures, the air-gap magnetic flux is relatively sinusoidal compared to the single-layer. Moreover, the torque generation is flexible by securing the q-axis flux path. In other words, the multi-layer structure is used despite the difficulties of productivity due to this advantage. It is analyzed how the multi-layer structure affects the field weakening region. Additionally, the Total Harmonics Distortion (THD) and reluctance torque are analyzed according to changes in the number of magnet layers. As a result, the higher the number of layers, the lower the THD and the greater the proportion of the use of reluctance torque. It is indicated that the voltage controllability in the field weakening control range is more effective if the rotor flux linkage is small when the maximum demagnetizing magnetomotive force is applied. Depending on the shape of the permanent magnet, the barrier changes simultaneously, and the d- and q-axis flux path also changes. So, the air gap magnetic field distribution and voltage control performance are changed. The performance of voltage controllability according to the shape of the magnet is compared by representing the magnetic flux density in the air gap. In Fig.2, if the flux linkage is small, the voltage controllability in the field weakening control region is more stable when the maximum demagnetizing magnetomotive force is applied. As a result, V-type models demonstrate effectively reducing total flux linkage over Bar type models. Lastly, the skew is applied for optimized design to reduce harmonics. The lowest voltage curve can be investigated in both the skew and the non-skew models for comparison of harmonic reduction using FFT analysis. In this paper, with the main aim of optimizing the characteristics in the field weakening control region and improving the voltage control performance, the design of a motor for driving 300kW commercial EVs with a wide range of field weakening control region is presented.

**References:**

[1]Ki-Chan Kim, "A Novel Magnetic Flux Weakening Method of Permanent Magnet Synchronous Motor for Electric Vehicles", IEEE Transactions on Magnetics, Vol.48, No.11, p.4042-4045 (2012) [2]J. A. Guemes, A. M. Iraolagoitia, and P. Fernandez, “Torque Analysis in Permanent-Magnet Synchronous Motors: A Comparative Study”, IEEE Transactions on Energy Conversion, Vol.26, No.1 p.55-63 (2011) [3]Jung-Min Mun, Yong-Jae Kim, and Sang-Yong Jung, "Design Characteristics of IPMSM With Wide Constant Power Speed Range for EV Traction”, IEEE Transactions on Magnetics, Vol. 53, No.6 (2017) [4]Mohammad Sedigh Toulabi, John Salmon, and Andrew M. Knight, “Concentrated Winding IPM Synchronous Motor Design for Wide Field Weakening Applications”, IEEE Transactions on Industry Application, Vol.53, No.3 p.1892-1900 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/cb8f3fa65f04b2fffc98850c049c66f4.jpg)
Comparison of the lowest line voltage with different number of slots

![](https://assets.underline.io/uploads/markdown_image/1/image/bd596c5eb22c3a03064e9bf2ac8f85b6.jpg)
The comparison of the total flux linkage between 2-layers V-type and Bar-type model

 A Design of IPMSM High-Power Electric Vehicles with Wide Field Weakening Control Region

I Introduction Permanent magnet synchronous machines (PMSMs) have been widely used in electric vehicle industry for their characteristics of high efficiency and power density. However, the development of PMSMs is limited by the unalterable permanent magnet (PM) excitation field. The flux-weakening control used in PMSMs can bring about high copper loss, low efficiency, and PM demagnetization. Variable-flux PMSMs are considered as a good candidate for EV propulsion because the speed range is wider and the operation efficiency is higher than traditional PMSMs. Variable-flux PMSMs employ low coercive force magnets, whose magnetization state can be adjusted by d-axis current pulses [1]. The PM excitation field is adjustable and the need for continuous flux-weakening current is reduced. Two schemes of novel hybrid-PM variable-flux PMSMs with series-parallel magnetic circuits are proposed in this paper. The performances of these two machines are analysed and compared with series-connected and parallel-connected machines. Moreover, the efficiency characteristic of the proposed machine under different magnetization states and load conditions is evaluated. A control strategy of appropriately combining magnetization state adjustment control and flux-weakening control is proposed, which can obviously improve the efficiency in full speed range, especially in high-speed region, by manipulating the magnetization state. II Machine Topology and Operating Principle Two schemes of variable-flux PMSMs with series-parallel magnetic circuits are proposed, as shown in fig.1, which are the single-layer V-type and two-layer V-U-type machines. The red coloured magnets are AlNiCo and blue coloured ones are NdFeB. As shown in fig. 1(a), the V-shape magnets are placed in the V-type machine. The NdFeB is connected with AlNiCo in series near q-axis, and these two series-connected magnets are connected with another AlNiCo located near d-axis in parallel. As shown in fig. 1(b), two layers of magnets are placed in the V-U-type machine. The series-connected U-shape NdFeB and AlNiCo magnets are placed under the V-shape magnets. The magnetization state of proposed machines can be adjusted by manipulating the magnetization direction of AlNiCo near d-axis in V-shape magnets and the flux amplitude of all AlNiCo. More details about the operating principle are analysed in full paper. III Performance Comparisons Electromagnetic performances, including back-EMF, torque capacity, stability of AlNiCo and magnetization state adjustment range, of the proposed machines are analysed and compared with parallel-connected and series-connected machines. Under fully forward magnetized state, the fundamental amplitudes of no-load EMF of V-type and V-U-type series-parallel-connected, parallel-connected and series-connected machines are 168V, 180V, 165V and 187V respectively. And those under fully reversed magnetized state are 58V, 60V, 38V and 120V. The magnetization ratios are 65.5%, 66.7%, 77.0% and 35.8%. Other performances are also compared in detail in full paper. After the comprehensive comparison, the proposed V-U-type series-parallel-connected machine is selected. The magnetizing/demagnetizing current density of V-U-type machine is 17.5A/mm2, which is smaller than that in [2-4]. The torque density of V-U-type machine is nearly the same with that in [3-4], and larger than that in [2]. The analysis results show that the proposed V-U-type series-parallel-connected machine combines the advantages of parallel-connected and series-connected variable-flux PMSMs. IV Efficiency Improvement through Magnetization State Adjustment The expanded speed range and efficiency improvement in high-speed region are the distinct advantages of the proposed machine. The maximum achievable torque-speed ranges at 4 typical magnetization states are evaluated. The speed range is significantly expanded by manipulating the magnetization state. The operating efficiency of the proposed machine at 4 magnetization states are evaluated. The efficiency can be significantly improved by adopting appropriate magnetization states at different working points. A control strategy to improve efficiency by adjusting magnetization state is proposed. For uncertain working conditions, a steady-state efficiency maximizing control strategy is proposed. The magnetization states whose operating efficiency is highest at every torque-speed working point are selected based on the efficiency characteristic at different magnetization states, as shown in fig. 2. A LUT is formed by the selected magnetization states. A hysteresis integral comparator is proposed to minimize the unnecessary magnetization state adjustment. The steady-state efficiency maximizing control is achieved by choosing magnetization states through the LUT and minimizing unnecessary magnetization state adjustment through the hysteresis integral comparator. For certain working conditions, like WLTC, an efficiency maximizing control strategy considering magnetization state adjustment loss is proposed. Optimal magnetization states at every working point are selected based on Genetic Algorithm. The optimization target is to minimize the whole drive cycle loss including the steady-state loss at each working point and the magnetization state adjustment loss. The results prove that the operation efficiency is significantly improved by adopting the proposed magnetization state adjustment strategy.

**References:**

[1] V. Ostovic. "Memory Motors," IEEE Ind. Appl. Mag., 9(1): 52-61, 2003. [2] N. Limsuwan, T. Kato, K. Akatsu, et al. "Design and Evaluation of a Variable-Flux Flux-Intensifying Interior Permanent-Magnet Machine," IEEE Trans. Ind. Appl., 50(2): 1015-1024, 2014. [3] A. Athavale, K. Sasaki, B. S. Gagas, et al. "Variable Flux Permanent Magnet Synchronous Machine (VF-PMSM) Design Methodologies to Meet Electric Vehicle Traction Requirements with Reduced Losses," IEEE Trans. Ind. Appl., 53(5): 4318-4326, 2017. [4] H. Hua, Z. Q. Zhu, A. Pride, et al. "Comparative Study on Variable Flux Memory Machines with Parallel or Series Hybrid Magnets," IEEE Trans. Ind. Appl., 55(2): 1408-1419, 2019.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/89944429fdc8a6824df6f50b6fd02901.jpg)
Fig.1 Two schemes of the proposed machines.

![](https://assets.underline.io/uploads/markdown_image/1/image/53ce01543de2d432e4a23087dffdad54.jpg)
Fig.2 Selected magnetization states with highest efficiency at each working point.

 Study of a High-Efficiency Series-Parallel-Connected Hybrid-PM Variable-Flux Permanent Magnet Synchronous Machine

I Introduction Variable-flux permanent magnet synchronous machines (PMSMs) have gained a lot of attention for their ability to expand speed range and reduce copper loss by manipulating the magnetization state dynamically. Variable-flux PMSMs employ low coercive force magnets, whose magnetization states can be adjusted by d-axis current pulses [1-2]. The PM excitation field is adjustable and the need for continuous flux-weakening current is reduced. To maximize output torque and operation efficiency, the maximum torque per ampere (MTPA) control is widely used in interior PMSMs [3-4]. However, the parameters, like PM flux-linkage, d- and q-axis inductances, of variable-flux PMSMs are influenced by not only the load condition variations but also the magnetization state adjustments. The precise MTPA control for variable-flux PMSMs is highly affected by the nonlinear parameter properties. The operating principle of a novel variable-flux PMSM is analysed. The nonlinear load flux-linkage model is established to simplify the modelling of nonlinear parameter properties. The MTPA current trajectory search method based on Golden Selection method is proposed to obtain the current trajectory considering the influence of magnetization state adjustments and load condition variations. Moreover, the on-line MTPA control method based on neural-network algorithm is proposed to provide an effective way of on-line MTPA control for variable-flux PMSMs. II Operating Principle of Variable-flux PMSMs and Nonlinear Load Flux-Linkage Model A novel series-parallel-connected hybrid-PM variable-flux PMSM is proposed and shown in fig. 1. The magnetization state of this machine can be adjusted by manipulating the magnetization direction of AlNiCo near d-axis in V-shape magnets and the flux amplitude of all AlNiCo. The machine saturation degree varies significantly with magnetization state adjustments and load condition variations. Then the machine parameters, such as PM flux-linkage, d- and q-axis inductances, vary nonlinearly too. The nonlinear load flux-linkage model is established to simplify the modelling of nonlinear parameter properties. The amplitude-phase sequences of current working points are selected to calculate the corresponding d-, q-axis flux-linkage by FEA or experiment. And the permeability of any two adjacent selected points is nearly the same. The nonlinear load flux-linkage model is formed using the selected current working points and corresponding d-, q-axis flux-linkage. The separation of load PM flux-linkage and calculation of d-, q-axis inductances are no longer needed. The load flux-linkage model that presents the nonlinear parameter properties is used in the MTPA current trajectory search process. III MTPA Current Trajectory Search based on Golden Selection Method The proposed MTPA current trajectory search method includes two iterative loops which are both based on Golden Selection method. The current phase iterative loop is implemented firstly, and the optimization target is to minimize corresponding current amplitude at a given torque reference and a given magnetization state. The amplitude is optimized to the minimum value when the iteration interval of phase is within a given minuscule number. However, the corresponding amplitude of phase cannot be obtained directly due to nonlinear parameter properties. The current amplitude iterative loop is nested in the phase iterative loop to obtain corresponding amplitude of each phase. The target of amplitude iterative loop is to optimize the difference between present torque and torque reference to zero. During the amplitude iteration process, the value of present torque under different amplitudes and phases is calculated by the nonlinear load flux-linkage model. MTPA current trajectories of the proposed machine under 4 magnetization states are obtained by the proposed search method, and compared with the trajectories obtained by traditional method, as shown in fig. 2. The current trajectories are evaluated by FEA and experiments. The results prove that the proposed search method can find MTPA current trajectories precisely considering the influence of magnetization state adjustments and load condition variations. IV On-Line MTPA Control based on Neural-Network Algorithm The on-line generation of current commands by the proposed search method is time-consuming. The neural-network-based MTPA control method is proposed to implement MTPA control in real-time control system. The MTPA current trajectory generated by proposed search method under different magnetization states and torque references are selected as sample data. The on-line MTPA control neural-network model is trained, tested and validated using sample data. The model input is magnetization state and torque reference, and the output is current amplitude and phase. Once the train, test and validation process are finished, the knowledge about input-output relationship is acquired and the on-line MTPA control neural-network model is established. MTPA current trajectories at any magnetization state and torque reference can be predicted by this model. The mathematical expressions of established model are easily programmed and quickly executed by DSP for on-line MTPA control. The calculation speed and accuracy are evaluated by simulations and experiments. The results prove that the proposed neural-network model can realize on-line MTPA control for variable-flux PMSMs quickly and precisely.

**References:**

[1] V. Ostovic. "Memory Motors," IEEE Ind. Appl. Mag., 9(1): 52-61, 2003. [2] H. Hua, Z. Q. Zhu, A. Pride, et al. "Comparative Study on Variable Flux Memory Machines with Parallel or Series Hybrid Magnets," IEEE Trans. Ind. Appl., 55(2): 1408-1419, 2019. [3] S. Kim, Y. D. Yoon, S. K. Sul, et al. "Maximum Torque per Ampere (MTPA) Control of an IPM Machine Based on Signal Injection Considering Inductance Saturation," IEEE Trans. Power Electron., 28(1): 488–497, 2013. [4] J. H. Chen, J. Li and R. H. Qu. "Maximum-Torque-per-Ampere and Magnetization-State Control of a Variable-Flux Permanent Magnet Machine," IEEE Trans. Ind. Electron., 65(2): 1158–1169, 2018.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/dfd2667da240b269f350b75ad5c8e9cf.jpg)
Fig.1 Structure of proposed machine.

![](https://assets.underline.io/uploads/markdown_image/1/image/a7ca35c45edd083408f18282dbf1d1bf.jpg)
Fig.2 Current trajectories obtained by proposed method and traditional method.

 Maximum Torque per Ampere Control for Variable-Flux PMSMs Considering the Influence of Magnetization State Adjustments and Load Condition Variations

This digest investigates the flux intensifying (FI) characteristics for permanent magnet assisted synchronous reluctance motor (PMa-SynRM) to achieve high torque density with a small amount of PM. This motor is particularly denoted as "FI-PMa-SynRM". The developed FI-PMa-SynRM is then compared with two other counterparts, i.e., a surface permanent magnet synchronous motor (SPMSM) and a synchronous reluctance motor (SynRM). The analysis is conducted using finite element method through flux linkage and inductances so that the effectiveness of FI characteristics is demonstrated. The analysis shows that a high torque density (24.8 Nm/L) can be achieved with a small amount of PM (0.72% motor volume). I. Motor Models Flux intensifying (FI) rotor configuration has been of recent interest as an alternative to conventional permanent magnet synchronous motors (PMSMs) which usually adopt flux weakening feature [1], [2]. By using a moderate amount of PM, the FI configuration can be applied to synchronous reluctance motor (SynRM), which leads to the introduction of FI permanent magnet assisted SynRM (FI-PMa-SynRM) [3]. In order to minimize the amount of PM used, a surface-inset PM design is employed, indicating that the rotor configuration can be considered as the combination of a SynRM with multiple flux barriers (FBs) and a surface PMSM (SPMSM), as shown in Fig. 1(a). This configuration (PM placed along d-axis) differs from common PMa-SynRM (PM placed along q-axis) so that PM flux linkage is intensified by part of the armature flux. This is called "FI" as illustrated in Fig. 1(b), making PM not easily demagnetized in such a configuration. Two other models with the same rotor shapes are used for comparison: the first one is an inset SPMSM (only eliminating interior FBs when compared to the developed FI-PMa-SynRM) that represents the flux weakened motor while the second one is a SynRM (only removing PMs based on the FI-PMa-SynRM) with only reluctance torque, as indicated in Fig. 1(a). The motor specifications are presented in Table I. II. Analysis and Results A. Distribution of magnetic field - The no-load condition is considered first, where the flux lines and flux densities are shown in Fig 1(c). It can be seen that for the FI-PMa-SynRM the flux focuses on the region between two adjacent interior FBs. For the inset SPMSM the flux focuses around the PMs. However, the PM operating conditions are similar since the flux density distributions in the PMs are basically affected by their relative positions to the stator slots. - Fig. 1(d) shows the motor flux densities under the maximum torque per ampere (MTPA) control where the FI-PMa-SynRM and SynRM operated with negative current phase advance angles with the SynRM having a greater phase advance. These all correspond to the phasor diagrams presented in Fig. 1(b). - The PM flux densities of the FI-PMa-SynRM and inset PMSM at -25 degrees (current phase advance) based on MTPA control of FI-PMa-SynRM are shown in Fig. 1(e). The negative current phase advances indicate that these motors operate in the FI mode. As can be seen, the overall flux densities in the PM seem to increase with applied current although part of the PMs may still suffer lower operating points. However, when the inset SPMSM operates in the MTPA condition, a positive current phase advance (19 degrees) is required, and the PM operating points are much lower due to flux weakening, which is also shown in Fig. 1(e). These imply that the PM is more secure with FI and the torque density can be possibly improved without suffering demagnetization. B.Inductance variation The inductances vs current amplitude when applying current on the d-axis are shown in Fig. 1(f). It can be seen that, for both the FI-PMa-SynRM and SynRM, Ld is higher than Lq so that the saliency, i.e. Ld/Lq of these models is higher than 1. Nevertheless, Ld of the SynRM is rapidly reduced with current increase while that of the FI-PMa-SynRM maintains. For the inset SPMSM, Ld is slightly lower than Lq and they both decrease when current magnitude increase so that the saliency is slightly lower than 1. C.Torque production Fig. 1(g) shows the torque vs current angle of these motors at both rated and peak currents. The MTPAs of the FI-PMa-SynRM and SynRM are achieved with negative current phase advance and that for the inset SPMSM is achieved with a positive phase advance. Moreover, with an added PM amount of just 0.72% of motor volume, the FI-PMa-SynRM has 1.77 and 1.34 times torque of that of the SynRM at rated and peak currents, respectively. On the other hand, by adding some FBs, the FI-PMa-SynRM produces 1.4 and 1.73 times torque of that of the inset SPMSM at the rated and peak currents, respectively. This indicates that the FI-PMa-SynRM is capable of effectively combining reluctance torque or PM torque compared to the other types of motors. As a result, this motor achieved high torque density, i.e. 13.45 Nm/L and 24.8 Nm/L at rated and peak conditions, respectively. D. Measurements The experimental results based on the prototype shown in Fig. 1(a) will be reported in the full paper. III. Conclusion This digest compares the characteristics of the designed FI-PMa-SynRM and its counterparts. The results revealed that the target FI-PMa-SynRM can achieve higher torque density than its counterparts by using a small amount of PM.

**References:**

[1] N. Limsuwan et al, IEEE Trans. Ind. Appl., vol. 50, no. 2, pp. 1015–1024, Mar. 2014. [2] M.-T. Chui et al, 2015 18th International Conference on Electrical Machines and Systems (ICEMS), Oct. 2015, pp. 232–236. [3] D.-K. Ngo, M.-F. Hsieh, and T. A. Huynh, IEEE Trans. Magn., vol. 55, no. 7, pp. 1–8, Jul. 2019.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/2d6c81d432c420ef48d64af683fd1974.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/7b37cb7115558e9622ed8f166329d82d.jpg)

 Flux Intensifying Features of Permanent Magnet Assisted Synchronous Reluctance Motor with High Torque Density

I. Introduction Permanent magnet (PM) motors have been widely used in electric vehicles due to its high torque/power density and high efficiency. Yet, a relatively constant airgap magnetic field of PM motors may limit the speed range to large extent, which is still the shortfall for the further applications in EVs. In recent years, a type of variable-flux-leakage PM motor is emerged, which draws intense interest from academics of motor field because of the achievement of flux-controllable capability [1]. In this type of motors, the leakage flux can be varied by designing flux bridge and magnetic barrier, and it can be controllable through the change of q-axis current of winding. Compared with conventional PM motor, the variable flux is essentially derived from active design of flux leakage. So, the magnetic field distribution of leakage flux is sensitively linked to the flux controllability. Then, in [2], a variable-flux-leakage PM Motor is proposed, where a unique flux leakage path is purposely considered by arranging the PM position and magnetic barrier reasonably. The results indicate that the relatively obvious capability of flux regulation is achieved by effectively controlling the leakage flux. Yet, in flux-regulated process, the magnetoresistance characteristic of the motor is changed appreciably caused by the variation of leakage flux. It means that different flux-leakage operation modes of the motor will bring the characteristic differences of output torque. For instance, the varied main flux caused by leakage flux greatly leads to the change of PM torque, while the variation of inductance characteristics induced by magnetic saturation bring about the change of reluctance torque. Therefore, to the variable-flux-leakage PM motor, it is necessary and meaningful to comprehensively consider the torque characteristics at various flux-leakage operation modes. And, in this case, how to realize the optimal distribution of different torque components is full of challenge. In this paper, a flux-controllable permanent magnet (FC-PM) motor is proposed. The key of the study is to conduct torque characteristics analysis and optimization by combining with typical operation conditions. Then, based on different flux-leakage operation modes, a reasonable optimization strategy considering torque components is developed. The results reveal that, based on optimization, the comprehensive torque is effectively improved while maintaining a desirable flux regulation region. II. Motor Topology and Simulation Result Fig.1(a) shows the structure of the FC-PM motor with independent separated flux leakage branches. It can be seen that the q-axis is equipped with multi-layer arc and ellipse magnetic barriers to obtains good magnetic flux leakage controllable performance, which further broadens the motor speed regulation range. Fig.1(b) shows the magnetic density distributions of the FC-IPM motor under different flux-leakage operation modes, and the corresponding requirements of torque components distribution are listed. In Fig. 2(a) and (b), the sensitivity of each design variable to different design objectives is evaluated, and three variables with high sensitivity are selected for further optimization. Fig. 2(c) and (d) show the result of torque distribution under different flux-leakage Operation Modes, which can be seen that through the multi-objective optimization proposed in this paper, the torque quality is improved as expect. The torque performances and corresponding torque component distribution under different modes are shown in Fig.2 (d) and (f). The prototype of proposed FC-IPM motor and corresponding experiment result of back-EMF are shown in Fig. 2(g) and Fig. 2(h), respectively. In additional, III. Conclusion In this paper, a FC-PM motor is purposely designed, and a multi-objective optimization method is also newly proposed, where the optimal distribution of torque components under different flux-leakage operation modes is considered. Through optimization, the PM torque becomes the main component under less flux leakage, and the reluctance torque as the main component under more flux leakage. It means that the optimal proportion of different torque components of the FC-PM motor is realized. Both the simulation and experiment results not only verify the reasonability of the proposed motor but also confirm the effectiveness of the proposed optimization method. The more electromagnetic performance analysis and experimental results will be provided in the full paper.

**References:**

[1] X. Zhu, W. Wu, S. Yang, Z. Xiang and L. Quan, in IEEE Transactions on Energy Conversion, vol. 33, no. 4, pp. 2260-2269, Dec. 2018. [2] T. Kato, M. Minowa, H. Hijikata, K. Akatsu and R. D. Lorenz, in IEEE Transactions on Industry Applications, vol. 51, no. 5, pp. 3811-3821, Sept.-Oct. 2015.

**Images:**
![](https://assets.underline.io/uploads/markdown_image/1/image/374892bf3a14e058bbeaa3286988bcda.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/4178320d508adb7f7bdb56859b57fb75.jpg)

 Torque Characteristics Investigation of A Flux-controllable Permanent Magnet Motor Considering Different Flux-leakage Operation Modes

I. INTRODUCTION The traditional three-phase PMSMs are confronted with severe challenge, and some researchers turn to investigate modular motor systems for better fault-tolerant capability [1]. The modular motor system is composed of several modules, and each module could be equivalent to an independent sub-motor. The better the independence of electric, magnetic, thermal, and physics between the modules, the better fault-tolerant performance of the motor is. The fractional slot concentrated winding (FSCW) has some advantages in non-overlapping end winding, large inductance and small coupling between phases, so it is very suitable for the application in modular fault-tolerant motors [2] However, the MMF of the motor with FSCW contains quantities of space harmonics which will cause PM eddy-current losses. The open-circuit fault is a typical fault in all kinds of motor faults [3], and the fault-tolerant capability of the motor is mostly determined by the output performance under open-circuit faults [4]. This paper investigates the influence of magneto motive force (MMF) space harmonic on permanent magnet (PM) eddy-current losses in a modular fault-tolerant in-wheel motor under various open-circuit faulty operations. First, reconfiguring maximum round MMF with constant amplitude of current is taken as the fault-tolerant (FT) strategy for the open-circuit of one phase. The fault-tolerant strategies for various faults are derived respectively based on this strategy. Second, the harmonic components of MMF under various faults and corresponding fault-tolerant control are analyzed respectively. Then, an analytical model based on multi-loop method for PM eddy current losses is proposed. The losses induced by each harmonic components of MMF can be obtained from the model. The analytical results agree well with the finite element method (FEM) results. The space harmonics are composed of slot harmonics and other harmonics. The proportions of eddy current losses caused by these two types of harmonics under various faults are derived. Finally, PM eddy-current losses induced by the fault-tolerant current under the overload condition are analyzed, and the results have a certain reference value for the fault-tolerant strategy which makes the faulty motor operates safer and more stable. II. MODULAR MOTOR SYSTEM WITH FAULT-TOLERANT CAPABILITY For design a better fault-tolerant motor, the entire fault-tolerant system needs to be considered comprehensively. Not only design the motor itself, but also should consider the topology of the controller and the fault-tolerant control strategy. The motor consists of 4 modules, as shown in Fig. 1. Each module is controlled by an independent drive with a three-phase four-wire control circuit, which ensures electrical isolation between the modules. III. ANSLYSIS OF CHARACTERISTICS OF MMF UNDER VARIOUS OPEN-CIRCUIT FAULTY OPERATIONS 1) Reconfiguring Maximum Round Fundamental MMF With Constant Current When A1 is in open-circuit condition, the performance of MMF will be declined. Quantities of sub-harmonics and high order harmonics closed to the working wave emerge, and the amplitude of working wave decreases, as shown in Fig. 2. Through the proposed fault-tolerant control, the performance of MMF is improved. 2) Spatial Harmonic Analysis of MMF under Various Faults The overall performance evaluation of the MMF is established by the two following aspects: 1 The amplitude of the working wave; 2 Total harmonic distortion (THD). The performance of MMF for the modular motor under various open-circuit faults can be effectively improved through the proposed fault-tolerant strategies. IV. ANSLYSIS OF PM EDDY-CURRENT LOSSES UNDER VARIOUS LOSSES UNDER VARIOUS OPEN-CIRCUIT FAULTY OPERATIONS 1) Analytical Model An analytical model based on multi-loop method for PM eddy current losses is proposed. 2) Verification by FEM The eddy-current losses of PMs by FEM consist of two parts. One is the slot ripple losses in PMs, which are the most important losses in PMs and generated by the fundamental frequency magnetic flux due to the stator slot openings. The other one is the losses in PMs induced by the space harmonics. The analytical results agree well with the FEM results. 3) Analysis of PM Eddy-Current Losses under Overload Fault-Tolerant Control When the overload FT controls are adopted, the motor can operate safely for a period of time rather than a long time. If we want the motor operates stably during the time, the PM losses should be considered. V. CONCLUSIONS An analytical model based on multi-loop method for calculating PM eddy-current losses is proposed. The analytical results agree well with the FEM result, which proves the correctness of the model. The proposed model is more accordant with the actual situation and the physical meaning is clearer. The eddy-current losses caused by high order slot harmonics are very small. Among the newly emerged harmonics, the sub-harmonics and high order harmonics closed to working wave will cause relatively large eddy-current losses. As the fault level increases, the proportion of eddy-current loss induced by slot harmonics decreases, while the proportion of eddy-current loss induced by other harmonics increases. If the overload fault-tolerant strategy is adopted, not only the copper losses but also the eddy-current losses of PMs should be considered.

**References:**

[1] Ifedi C. J., Mecrow B. C., Brockway S. T. M, “Fault-tolerant in-wheel motor topologies for high-performance electric vehicles”. IEEE Trans. Ind. Appl., 2013, 49, (3), pp. 1249-1257. [2] Heins G., Ionel D., Thiele M., “Winding factors and magnetic fields in permanent magnet brushless machines with concentrated windings and modular stator cores”. IEEE Trans. Ind. Appl., 2015, 51, (4), pp. 2924–2932. [3] Li Y. X., Zhu Z. Q., Thomas A. S., “Novel modular fractional slot permanent magnet machines with redundant teeth”. IEEE Trans. Magn., 2019, 55, (9), pp. 1-10. [4] Liang P. X., Pei Y. L., Chai F., “An improved method for armature-reaction magnetic field calculation of interior permanent magnet motors”. IEEE Trans. Magn., 2016, 52, (7), pp. 1-4.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/b5f8d38fe4176b0605a175e03295d3aa.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/3dbccfaa57183c0d06276f162998ca2a.jpg)

 Influence of MMF Space Harmonic on PM Eddy-Current Losses in a Modular Fault-Tolerant In-Wheel Motor under Open-Circuit Faulty Operations

This paper presents a comparative study of the field modulation effects (FMEs) on consequent-pole permeant magnet (CPM) machines with different stator slot configurations, i.e., open-slot, semi-closed slot and close-slot. Due to the asymmetrical PM magneto-motive force (MMF) distributions and double-side slotting effect, the CPM machines exhibit more air-gap field harmonics for the torque production. In order to quantify the torque contributions of the various effective harmonics, the Maxwell stress tensor method (MSTD) is adopted. The torque proportions due to various air-gap field harmonics in the CPM machines with different stator slot configurations are subsequently investigated by finite element (FE) method, which confirms that the stator slot configurations have a great influence on FME. It can be found that the highest and the lowest torque proportion contributed by the modulated field harmonics can be observed in closed-slot and open-slot structures, respectively. Finally, some experimental measurements on a 12-slot/14-pole CPM machine prototype with a semi-closed slot configuration are carried out to validate the theoretical and FE analyses. I. Introduction In order to reduce permanent magnet (PM) consumption, consequent-pole PM (CPM) machines are widely investigated with hybrid excited [1], modular design [2] and multi-phase [3] in recent years. Besides, some interior CPM machines with different PM arrangements, i.e., V-shaped [4], U-shaped [5] and spoke-type [5]-[7] are studied. It demonstrates that the proposed designs exhibit comparable torque performance, high-efficiency region and relatively lower PM consumption than conventional counterparts. Moreover, the field modulation effect (FME) on CPM machine is comparatively studied with surfaced-mounted PM (SPM) machine, which shows that the CPM machine exhibits more pronounced FME than SPM case due to its double-side slotting effect [8] [9]. However, the influence of stator slot on FME of the CPM machines remain unexplained hitherto. Thus, this paper comparatively study of the FME on CPM machines with different stator slots, i.e., open-slot, semi-closed slot and closed-slot. II. Machine Topologies The illustrations of 12-slot stators with open-slot, semi-closed slot and closed-slot structures are given in Fig. 1(a), (b) and (c), respectively. In order to perform a fair comparison, the three CPM machines share the same 14-pole rotor, as shown in Fig. 1(d). Besides, in order to identify and compare the effective air-gap field harmonics for the torque production in a fair way, the same stator outer diameter, air-gap length, active stack length and current density are employed in the three CPM machine topologies. III. Comparison of Torque Contributons of Dominant Magnetic Field on CPM Machies The torque characteristics of the three CPM machines are illustrated in Fig. 1(e) and (f). It can be observed that the semi-closed slot structure exhibits the highest torque, as shown in Fig. 1(e), which is mainly due to its the lowest flux leakage. According to Maxwell stress tensor method, the instantaneous electromagnetic torque Te can be calculated by Τe=(lstkrg2/μ0)∫BrBtdθ=∑(πlstkrg2/μ0)BrkBtkcos[θrk(t)-θtk(t)]=∑Tk(t) (1) where rg is the air-gap radius. lstk is the active stack length. Tk is the instantaneous electromagnetic torque generated by the kth harmonics of radial and tangential air-gap flux densities, respectively. Thus, the contributions of the kth field harmonics to the total electromagnetic torque can be separated when the kth radial and tangential air-gap field harmonics are obtained, as illustrated in Figs. 1(f). It should be noted that, apart from the Zr order magnetic harmonic, various modulated field harmonics engage in the torque generation, which confirm that the pronounced FME in CPM machines. Besides, the Zr order harmonic contributes the highest and lowest torque proportion in open-slot and closed-slot, respectively. As a result, the highest and the lowest torque production contributed by the modulated field harmonics can be observed in closed-slot and open-slot structures, respectively. IV. Experimental Validation The stator and rotor assemblies of the CPM machine prototype with semi-closed slot configuration are shown in Figs. 2(a) and (b), respectively. The comparison of the FE predicted and measured back-EMF and average torque values are illustrated in Figs. 2(c) amd (d), respectively. Because the end flux leakage and mechanical tolerance are not considered in the FE analyses, the slight difference between the FE predicted and measured results can be observed in Figs. 2(c) and (d). Overall, a satisfactory agreement between the measured and FE predicted results confirms the theoretical analyses. The detailed analysis will be presented in the full paper.

**References:**

[1] J. A. Tapia, F. Leonardi and T. A. Lipo, IEEE Transactions on Industry Application, Vol. 39, p.1704-1709 (2003) [2] S. U. Chung, J. W. Kim and B. C. Woo IEEE Transactions on Magnetics, Vol. 47, p.4215-4218 (2011) [3] H. Dhulipati, E. Ghosh and S. Mukundan, IEEE Transactions on Energy Conversions, Vol. 34, p.2041-2051 (2019) [4] J. Li, K. Wang and H. Zhang, IEEE Transactions on Industrial Electronics, Vol. 67, p.3374-3385 (2020) [5] J. Li and K. Wang, IEEE/ASME T Transactions on Mechatronics, Vol. 24, p.2182-2192 (2019) [6] W. Liu and T, A. Lipo, IEEE Transactions on Industry Application, Vol. 54, p.5918-5929 (2018) [7] X. Ren, D. Li and R. Qu, IEEE Transactions on Energy Conversions, Vol. 33, p.2112-2121 (2018) [8] Y. Li, H. Yang and H. Lin, in Proc. XIII International Conference Electrical Machine (ICEM), pp. 65-71 (2018) [9] Y. Li, H. Yang and H. Lin, IEEE Transactions on Energy Conversions, accepted. (2020)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/7b6b32fc69a3721b8bce95d338aa550e.jpg)
Fig. 1. Machine Topologies of the CPM design with different stator slot configurations. (a) Open-slot. (b) Semi-closed slot. (c) Closed-slot. (d) CPM rotor. Torque characteristics of the CPM machines with different stator slot configurations. (e) Steady-state torque. (f) Torque proportion of the main working harmonics.

![](https://assets.underline.io/uploads/markdown_image/1/image/0b10a474aeab2a426720f5f07c6bab42.jpg)

Fig. 2. The CPM machine prototype with semi-closed slot. (a) Stator. (b) Rotor. Comparison of the measured and FE predicted back-EMF and average torque values. (c) Back-EMFs. (d) Average torque versus phase current.

 Comparative Study of Field Modulation Effects on Consequent-Pole PM Machines with Different Stator Slot Configurations

Recently, regulations on carbon dioxide emissions caused by environmental problems have been promoted worldwide. In the automotive industry, engine vehicles are being regulated and will disappear on the road in the next 10 years. As a result, the market for low-carbon Fuel Cell Electric Vehicles and electric vehicles is expanding, and much research on electrical components is underway. Compared to engine vehicles, electric vehicles have better efficiency of the drive unit itself without using a transmission. However, it has the disadvantages of the high vehicle price, low All-Electric Range(AER), and long charging time. These reasons are due to the high price of batteries that go into electric vehicles. To reduce the price of the vehicle, it is necessary to improve the performance of the battery and AER. In other ways, the efficiency of electric motors, inverters can affect the improvement of mileage when the same battery is used. Therefore, research to minimize the loss of both motors and inverters is also needed. Due to the characteristics of the electric motor, it does not come out efficiently in all operating ranges. Especially when the electric motor enters the high-speed region, the efficiency will be further reduced. The model is IPMSM used in electric vehicles, and the concept of electromagnetic multi-step transmission is introduced. The electromagnetic multi-step transmission is a method in which the parallel branch of the stator is changed at a constant speed by using the switch. Using this method, high torque and efficiency in the low-speed range, high efficiency in the high-speed range, and the operating range were expanded. The operating characteristics were analyzed using the finite element method (FEM). Additionally, phenomena occurring in the shifting process were analyzed. To proceed with the analysis, a 2D model was made by using a simulation tool. The model was analyzed into two models to select the parallel branch conversion point. The model's size is the same, and it is divided into two models of parallel branch 2 and 4. The base speed and maximum speed of parallel branch 2 are 3,000rpm and 8,000rpm, and the base and maximum speed of parallel branch 4 are 6,000rpm and 10,000rpm. The efficiency characteristics of both models were derived and analyzed for expanding the high-efficiency operating range. By combining the efficiency characteristics of both models, the conversion point of the parallel branch in which the high-efficiency section at the time of shifting is formed most widely was selected at 6,000 rpm. Fig. 1 shows a circuit diagram for electromagnetic multi-step shifting. The stator winding is Y-connected, and the dotted line is the circuit in the low-speed range, and the number of parallel circuits for each A, B, C phase is 2. The solid line shows the circuit when the number of parallel circuits of each phase is changed to 4 through a switch. Change the number of parallel branch The switch used for contact used a thyristor and consisted of 12 terminal terminals. The phenomenon that may be displayed when the number of parallel branch increases in the same model is that the torque decreases. And it is possible to operate up to a higher speed region than the model in which the number of parallel branch is small in voltage saturation. In addition, it was derived that the current density is reduced, which is advantageous in terms of heat. This motor operates with parallel branch 2 in the low-speed range, and changes the number of parallel branch of the stator to 4 through a switch at 6,000rpm. The electric motor used in the model is driven by parallel branch 2 in the low-speed section and changes the number of parallel branch of the stator to 4 by using the switch at 6,000rpm. The parallel branch 2 is called 1-step, and the voltage is saturated in the low-speed range. Therefore, it generates high torque at low speed, and the maximum efficiency point appears at low speed due to voltage saturation. After 6,000rpm, it is referred to as 2-step, driven by parallel branch 4. And the voltage is saturated at 6,000rpm. Therefore, in the case of parallel branch 4, the range of maximum efficiency point is displayed at around 6,000rpm. Fig. 2 shows the waveform of the current flowing through the stator winding in the process of shifting from 1-step to 2-step through FEM analysis. It was derived that the current waveform was unbalanced when shifting from 1-step to 2-step. In addition, a current unbalance phenomenon appeared in the process of shifting from 2-step to 1-step. current imbalance generates an impact during the shifting process, and is defined as a shift shock. It was analyzed that the shift shock was caused by a phenomenon in which the current was delayed by inductance in the process of changing the switch to shift. A study was conducted on the phenomena and characteristics of the electric motor when the electromagnetic transmission system was introduced into the IPMSM for electric vehicles. As a method of expanding the high-efficiency range of the motor, a method of changing the number of parallel branch through the shift process was used. However, it was confirmed that a shift shock was generated by an unbalanced current during the shifting process. In order to alleviate the shift shock, additional research was conducted to reduce the shock by selecting a parameter related to the stator.

**References:**

[1] Ho-Chang Jung, Gyeong-Jae Park, and Sang-Yong Jung, IEEE Trans. Magn, Vol. 53, No. 6 (2017) [2] Liang Fang, Jae-woo Jung, and Jung-Ho Lee, IEEE Trans. Magn, Vol. 44, No. 11, pp. 4393-4396 (2008) [3] Se-Young Oh, Su-Yeon Cho, and Ju Lee, IEEE Trans. Magn, Vol. 50, No. 2 (2014) [4] Ho-chang Jung, Deokjin Kim, and Sang-Yong Jung, IEEE Trans. Magn, Vol. 50, No. 2 (2014) [5] SangHyeok Seo, Gyeong-Jae Park, and Sang-Yong Jung, IEEE Trans. Magn, Vol. 53, No. 6 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/77518ee0e3bb22fe77956141eab380ec.jpg)
Circuit diagram for electromagnetic multi-step transmission

![](https://assets.underline.io/uploads/markdown_image/1/image/c6accf0acdac7081b6485cebeeec4332.jpg)
Current waveform from 1st to 2nd step

 A Study on The Electromagnetic Multi-Step Transmission Characteristics of Interior Permanent Magnet Synchronous Motor

1. In order to extending the operating speed range and increasing the maximum torque, two design methodologies of variable-flux machines (VFMs) are proposed, which make full utilizing of the material properties of the low coercive force (LCF) magnet. The inner relationship between the permanent-magnet (PM) flux variation range and speed-torque curves is comprehensively analyzed. The variation boundary of the PM flux for non-salient-pole with id=0 control method is investigated by analytic method. Due to the complexity of the transcendental equations, the per unit system is utilized for other types of machine and control method. Because the hysteresis loops of the LCF magnet employed in VFMs are quite different, which makes it difficult for machine designers to select suitable magnet. Therefore, an ideal determination model of hysteresis loop is established considering the remanent flux density, permeability of the recoil line, knee point and coercive force of the LCF magnet. A custom method is proposed to obtain the hysteresis loop calculated form the determination model. By using the proposed methodologies, the material prosperities of the magnet can be fully utilized and provide guidance to the scholars in the initial design stage of the VFM. 2. Introduction: Owing to the controllability of the permanent-magnet (PM) magnetic field, the variable-flux machine (VFM) become a good candidate for wide-speed operating demanding areas. By applying instantaneous demagnetizing current pulse, the PM flux of the VFM can be changed with negligible copper loss [1]. Compared with the conventional PMSMs, the negative d-axis current control (flux-weakening control) used under high speed condition is superseded by the instantaneous current pulse, so the overall efficiency of the VFM can be improved. Moreover, since the no-load back electromotive force proportional to the PM flux is reduced, the machine can operate under higher speed. There are many VFM topologies proposed by scholars, which has demonstrated the concepts and verified the merits of the VFM in detailed. In order to improve the torque output capability, the hybrid-PM variable flux machines (HPM-VFMs) are proposed [2-5]. The low coercive force (LCF) magnet employed in the above mentioned VFMs are AlNiCo, SmCo and Ferrite. However, there are little design methodologies to improve the machine performance in terms of the full utilizing of the material properties of the LCF magnet. In order to address the issues mentioned above, the design methodologies of the VFM are studied in this paper. 3. Design methodology of the boundary of the PM flux variation range: Conventionally, in order to obtain wider speed range, the minimum PM flux is designed to be low enough. However, during the deeply studying of the relationship between the torque-speed curves and PM flux variation ratio, the curves of several flux variation ratio is always lower than other ratios, as shown in Fig. 1 (a).The result shows that it is unnecessary to pursuit wider flux variation range. In order to investigate the inner relationship between the flux variation ratio and speed-torque curves and find the boundary of the PM flux variation range, the machine performance is comprehensively analyzed considering the PM flux linkage, machine inductance, saliency ratio, bus voltage and current limit. The operation equations of the non-salient-pole VFM with id=0 control method is deduced, and then the PM flux variation boundary is obtained. For the non-salient-pole VFM, if the PM flux linkage after saturation magnetization is larger than the product of the d-axis inductance and the current limit, all machine always possesses speed extension capability by demagnetization process. The comparison of the torque-speed areas of the VFM with and without adopting the proposed methodology is shown in Fig 1 (c). The torque-speed curves after adopting the proposed in Fig 1 (c) is composed of many PM variation ratios. It can be seen form Fig 1 that machine 1 can obtain extra speed region after adopting the proposed methodology. The then boundaries of other types of machines and control methods are investigated. Due to the complexity of the transcendental equation, the per unit system is used. For the other machines, we can conclude that the minimum PM flux should be larger than the product of the d-axis inductance and the current limit. 4. Design methodology of the Optimum PM hysteresis loop: By comparing the hysteresis loops of the AlNiCo, SmCo and Ferrite, the hysteresis loops are quite different from each other, and it is necessary to find the suitable loop. An ideal determination model of hysteresis loop is established considering the remanent flux density, permeability of the recoil line, knee point and coercive force of the LCF magnet. The overall performance of the VFM are also considered, including maximum torque, re/demagnetization difficulty and anti-passive demagnetization ability, and the ideal hysteresis loop can be obtained. By connecting the LCF and the high-coercive force magnet in series and adjusting the ratio of the two magnet, we can customize the hysteresis loop. Based on the proposed model and the custom method of the hysteresis loop, a VFM with optimum PM hysteresis loop is designed. The simulation result shows that the PM torque of the VFM can be increased. By using the proposed methodologies, the material properties of the LCF magnet can be fully utilized.

**References:**

[1] V. Ostovic, IEEE Ind. Appl. Mag. , Vol. 9, p. 52 (2003) [2] M. Ge, J. Li and R. Qu, IEEE Trans. on Appl. Sup. Vol.28(3), p. 1-5 (2018) [3] H. Yang, Z. Q. Zhu and H. Lin, IEEE Trans. on Mag. Vol.53(5), p. 1-4 (2017) [4] A. Athavale, K. Sasaki, and R. D. Lorenz, IEEE Trans. on Ind. Appl. Vol.53, p.4318-4326 (2017) [5] Z. Q. Zhu, H. Hua, A. Pride, IEEE Trans. on Mag. Vol.53(11), p. 1-4 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/12801efde0326c8f2103714289521f41.jpg)
Comparison of the torque-speed areas of the VFM with and without adopting the proposed methodology

Torque-Speed Characteristics Evaluation for Permanent Magnet Synchronous Motors with Rectangular Conductors
